产品详情
MMA/Arc Welding Machine手工焊焊机系列 | ||||||||
| Parameter Model | ZX7/ARC/ MMA-200 | ZX7/ARC/ MMA-255 | ZX7/ARC/ MMA-318 | ZX7/ARC/ MMA-418 | ZX7/ARC/ MMA-318I | ZX7/ARC/ MMA-418I | ZX7/ARC/ MMA-500 | ZX7/ARC/ MMA-500 |
Rated input Voltage(V) 额定输入电压： | AC220V (50-60HZ) | AC220V/380V (50-60HZ) | AC220V/380V (50-60HZ) | AC220V/380V (50-60HZ) | AC220V/380V (50-60HZ) | AC220V/380V (50-60HZ) | AC220V/380V (50-60HZ) | AC220V/380V (50-60HZ) |
Input current(A) 额定输入电流： | 21 | 31 | 21 | 31 | 41 | 41 | 25.5 | 27 |
Rated Power Input (KVA) 额定输入功率： | 4.8 | 6.8 | 16 | 16 | 16 | 16 | 7 | 10 |
Rated No-Load Voltage 额定空载电压 | 68 | 68 | 68 | 68 | 68 | 68 | 68 | |
Output current range(A) 输出电流范围： | 200 | 200/255 | 0-318 | 0-418 | 0-318 | 0-418 | 0-500 | 0-630 |
Output Voltage(V) 输出电压： | 24 | 26 | 28 | 30 | 28 | 29% | 32 | 36 |
Rated duty cycle(%) 额定负载持续率 | 30℃ 100% | 30℃ 100% | 30℃ 100% | 30℃ 100% | 30℃ 100% | 30℃ 100% | 30℃ 100% | 30℃ 100% |
Insulation class 绝缘等级 | F | F | F | F | F | F | F | F |
| Protection degrees of the frame外壳防护等级 | IP21S | IP21S | IP21S | IP21S | IP21S | IP21S | IP21S | IP21S |
| Cooling mode冷却方式 | COOLING 风冷 | COOLING 风冷 | COOLING 风冷 | COOLING 风冷 | COOLING 风冷 | COOLING 风冷 | COOLING 风冷 | COOLING 风冷 |
| Package size 外箱尺寸（MM) | 760*360*265 5SETS/CTN | 540*360*260 4SETS/CTN | 730*370*280 4SETS/CTN | 730*370*280 4SETS/CTN | 730*370*280 4SETS/CTN | 730*370*280 4SETS/CTN | 485*245*45 4SETS/CTN | 485*245*45 4SETS/CTN |
| Package Weight 包装重量 | 17 | 15.4 | 22 | 23 | 22 | 22 | 15 | 16 |
