| WS/TIG WELDING MACHINE/ARGON WELDER SPECIFICATON: | |||||||
| Parameter Model | TIG200D 220v | TIG250D 220V | TIG MMA200S 220V/380V | TIG MMA250S 220V/380V | TIG315D 380V | TIG MMA315S 220V/380V | TIG400D 380V |
| Welding Form | argon | argon | argon/manual welding | argon/manual welding | argon welding | argon/manual welding | argon |
Rated input Voltage(V) 额定输入电压： | Single phase AC220V±15% | Single phase AC220V±15% | AC220V/380V±15% | Single phase AC220V±15% | AC220V/380V±15% | Three phase AC380V±15% | Three phase AC380V±15% |
Rated input Capacity(KVA) 额定输入电源容量： | 7KVA | 8.2KVA | 7KVA | 8.2KVA | 15.5KVA | 15.5KVA | 17.2KVA |
Rated input Current(A) 额定输入电流 | TIG:20A | TIG:28A | TIG:20A MMA:33A | TIG:28A MMA:43A | TIG:9.6A(380V) TIG:33.5A(220V) | TIG:9.6A MMA:14.4A | TIG:12.7A |
Rated output Voltage(V) 额定输出电压： | 18V | 20V | TIG:18V MMA:28V | TIG:20V MMA:30V | 22.6V | 22.6V | 26V |
No load Voltage(V) 空载电压： | 56V±5V | 56V±5V | 56V±5V | 65V±5V | 65V±5V | 65V±5V | 65V±5V |
Efficiency(%) 效率： | 80% | 80% | 80% | 80% | 80% | 80% | 80% |
Load duty cycle(%) 额定负载持续率 | 60% | 60% | 60% | 60% | 60% | 60% | 60% |
Output current range(A) 输出电流范围： | 0-200A | 0-250A | 0-200A | 0-250A | 0-315A | 0-315A | 0-400A |
Protection class 保护等级： | IP21 | IP21 | IP21 | IP21 | IP21 | IP21 | IP21 |
Power factor 功率因数： | 0.73 | 0.73 | 0.73/0.93 | 0.73 | 0.73/0.93 | 0.93 | 0.93 |
| Stainless steel thicknes | 5mm | 5mm | TIG:5mm MMA:10mm | TIG:5mm MMAl:12mm | 8mm | TIG:8mm MMA:20mm | 10mm |
